Pulsed 500 Watt — Specs & Setup
HTCM500 · SEAGULL3™
Pulsed MOPA fiber system for precision and delicate work — thin metal, wood, and stone. Low heat input protects the substrate.
HTCM500 · SEAGULL3™
Pulsed MOPA fiber system for precision and delicate work — thin metal, wood, and stone. Low heat input protects the substrate.
| Specification | Value |
|---|---|
| Model | HTCM500 (SEAGULL3™) |
| Laser type | Pulsed fiber (MOPA) |
| Laser source | JPT MOPA pulsed fiber |
| Max average power | 500 W |
| Wavelength | 1064 nm |
| Max pulse energy | 15 mJ (range 1.5–15 mJ) |
| Pulse width | 2–500 ns (JPT MOPA, adjustable) |
| Pulse frequency | 1–4,000 kHz (adjustable) full 15 mJ/pulse up to ≈ 33 kHz; per-pulse energy drops at higher rates |
| Cleaning modes | 8 (single-axis) / 13 (dual-axis) |
| Scan width | 0–5.7 in (0–145 mm) |
| Max scan speed | 98.4 ft/s (30 m/s ≈ 30,000 mm/s) |
| Fiber cable length | 32.8 ft (10 m), customizable |
| Cooling | Air-cooled |
| Input power | 220 V / 50 Hz, 1-phase (110 V / 60 Hz optional; universal 110–220 V, 50–60 Hz) |
| Whole-machine draw | 2.5–3 kW (≈ 11–14 A @ 220 V) |
| Cleaning gun weight | < 3.3 lb (< 1.5 kg) |
| Machine weight | 110 lb (50 kg) |
| Machine dimensions | 19.5 × 13.9 × 23.9 in (495 × 353 × 608 mm) |
| Operating temperature | 41–104 °F (5–40 °C) |
| Operating humidity | ≤ 80% |
| Cleaning rate | ≈ 161 ft²/h @ 0.8 mil paint or rust (15 m²/h @ 20 µm) |
| Certifications | CE, FDA |
| Warranty | 2-yr laser source / 1-yr machine |
